LTC2996CDD#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT 20/70DEG OPN DR 10DFN
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 930
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 10-WFDFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Published 2012
JESD-609 Code e3
Feature Utilizes External Sensor
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Sensors/Transducers
Technology CMOS
Voltage - Supply 2.25V~5.5V
Base Part Number LTC2996
Output Active High, Active Low
Pin Count 10
Body Length or Diameter 3mm
Body Breadth 3 mm
Output Type Open Drain
Power Supplies 3.3V
Termination Type SOLDER
Accuracy ±2°C
Current - Supply 200μA
Output Function /OverTemp, /UnderTemp
Sensors/Transducers Type TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT
Housing PLASTIC
Switching Temperature -20°C 70°C
Selectable Hysteresis No
Trip Temperature Threshold Cold Hot
Dimensions
Body Height 0.75mm
Compliance
RoHS Status ROHS3 Compliant
