TMP01FSZ
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
ANALOG DEVICES TMP01FSZTemperature Sensor IC, Voltage,3C, -40 C, +85 C, SOIC, 8 Pins
PDF
/
Buying Options
Total Price: USD $10.84
Unit Price: USD $10.84253
≥1 USD $10.84253
≥10 USD $10.2288
≥100 USD $9.64981
≥500 USD $9.1036
≥1000 USD $8.5883
≥3000 USD $8.10217
Inventory: 3303
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4mm
Length 5mm
Height 1.5mm
Technical
Trip Temperature Threshold Cold Hot
Selectable Hysteresis Yes
Switching Temperature Programmable
Housing PLASTIC
Sensors/Transducers Type TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT
Output Function /OverTemp, /UnderTemp
Accuracy ±1°C
Output Current 2mA
Nominal Supply Current 500μA
Operating Supply Current 500μA
Termination Type SOLDER
Power Supplies 5/12V
Max Output Current 50mA
Output Type Open Collector
Output Voltage 1.49V
Body Breadth 3.9 mm
Pin Count 8
Output Active High
Base Part Number TMP01
Voltage - Supply 4.5V~13.2V
Technology HYBRID
Subcategory Other Sensors/Transducers
Additional Feature TTL COMPATIBLE, CMOS COMPATIBLE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
