TMP01FS-REEL
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
Tape & Reel (TR) Active High TMP01 Surface Mount Programmable Thermostat 3.9mm 50mA 4.5V~13.2V -55C~125C
PDF
/
Buying Options
Total Price: USD $5.75
Unit Price: USD $5.7532
≥1 USD $5.7532
≥10 USD $4.72055
≥100 USD $4.5733
≥500 USD $4.42605
≥1000 USD $4.27785
Inventory: 1086
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Body Height 1.55mm
Technical
Trip Temperature Threshold Cold Hot
Selectable Hysteresis Yes
Switching Temperature Programmable
Sensors/Transducers Type TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT
Output Function /OverTemp, /UnderTemp
Accuracy ±1°C
Operating Supply Current 500μA
Termination Type SOLDER
Power Supplies 5/12V
Max Output Current 50mA
Output Type Open Collector
Body Breadth 3.9 mm
Body Length or Diameter 4.9mm
Output Active High
Base Part Number TMP01
Voltage - Supply 4.5V~13.2V
Subcategory Other Sensors/Transducers
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
