TMP01FJ
RoHS
/
Package TO-99-8 Metal Can
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
THERMOSTAT PROG ACTIVE HI TO99-8
PDF
/
Buying Options
Total Price: USD $20.27
Unit Price: USD $20.26825
≥1 USD $20.26825
≥10 USD $16.6307
≥100 USD $16.11105
≥500 USD $15.5914
≥1000 USD $15.07175
Inventory: 1157
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status CONTACT ADI (Last Updated: 2 weeks ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-99-8 Metal Can
Number of Pins 8
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature TTL COMPATIBLE, CMOS COMPATIBLE
Subcategory Other Sensors/Transducers
Technology HYBRID
Voltage - Supply 4.5V~13.2V
Reach Compliance Code not_compliant
Base Part Number TMP01
Output Active High
Pin Count 8
Output Type Open Collector
Max Output Current 50mA
Power Supplies 5/12V
Interface Serial
Termination Type SOLDER
Operating Supply Current 500μA
Nominal Supply Current 500μA
Accuracy ±1°C
Output Function /OverTemp, /UnderTemp
Sensors/Transducers Type TEMPERATURE SENSOR,ANALOG,VOLTAGE OUTPUT
Switching Temperature Programmable
Source Url Status Check Date 2013-05-01 14:56:54.967
Selectable Hysteresis Yes
Trip Temperature Threshold Cold Hot
Dimensions
Body Height 4.445mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
