ADT6504SRJZN015RL7
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description
IC TEMP SENSOR MICROPWR SOT23-5
PDF
/
Buying Options
Total Price: USD $6.07
Unit Price: USD $6.0667
≥1 USD $6.0667
≥10 USD $4.978
≥100 USD $4.8222
≥500 USD $4.6664
≥1000 USD $4.5106
Inventory: 1258
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Subcategory Other Sensors/Transducers
Voltage - Supply 2.7V~5.5V
Base Part Number ADT6504
Output Active High
Pin Count 5
Body Length or Diameter 2.9mm
Body Breadth 1.6 mm
Output Type Push-Pull
Max Output Current 20mA
Termination Type SOLDER
Operating Supply Current 30μA
Nominal Supply Current 30μA
Number of Bits 11
Accuracy ±4°C
Resolution 1.5 B
Sampling Rate 1.7 sps
Output Function UnderTemp
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SINGLE TRIP POINT
Switching Temperature -15°C
Selectable Hysteresis Yes
Trip Temperature Threshold Cold
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
