ADT6503SRJZN025RL7

Analog Devices Inc.
RoHS
RoHS RoHS compliant
Package SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Thermostats - Solid State
Description IC TEMP SENSOR MICROPWR SOT23-5
PDF
/
Buying Options
Total Price: USD $1.66
Unit Price: USD $1.661613
≥1 USD $1.661613
≥10 USD $1.567564
≥100 USD $1.47883
≥500 USD $1.39512
≥1000 USD $1.316154
Inventory: 995
Minimum: 1
-
+

Technical Details

Physical

Contact Plating Tin
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Subcategory Other Sensors/Transducers
Voltage - Supply 2.7V~5.5V
Base Part Number ADT6503
Output Active Low
Pin Count 5
Body Length or Diameter 2.9mm
Body Breadth 1.6 mm
Output Type Open Drain
Max Output Current 20mA
Termination Type SOLDER
Operating Supply Current 30μA
Nominal Supply Current 30μA
Number of Bits 11
Accuracy ±6°C
Resolution 1.375 B
Sampling Rate 1.7 sps
Output Function /UnderTemp
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SINGLE TRIP POINT
Switching Temperature -25°C
Selectable Hysteresis Yes
Trip Temperature Threshold Cold

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
