NCP15XM472J0SRC
RoHS
/
Package 0402 (1005 Metric)
Category Sensors, Transducers / Temperature Sensors - NTC Thermistors
Description
NTC THERMISTOR 4.7K OHM 5% 0402
PDF
/
Inventory: 6049
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0402 (1005 Metric)
Terminal Shape WRAPAROUND
Number of Pins 2
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series NCP15
Tolerance 5%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Resistance 4.7kOhm
Terminal Finish Tin (Sn)
HTS Code 8533.40.80.70
Power Rating 100mW
Max Power Dissipation 100mW
Depth 500μm
Resistor Type NTC THERMISTOR
Current Rating 460μA
Rated Power Dissipation (P) 0.1W
Lead Pitch 400μm
Terminal Placement DUAL ENDED
Accuracy 2 %
Resistance Tolerance ±5%
Thermistor Application TEMPERATURE SENSING
Resistance in Ω @ 25°C 4.7k
B Value Tolerance ±2%
B25/85 3545K
Thermal Sensitivity Index 3500 K
B25/50 3500K
B25/100 3560K
Dimensions
Length 1mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
