TMP442BDCNT
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-8
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
IC, TEMP SENSOR, 8SOT23
PDF
/
Buying Options
Total Price: USD $2.28
Unit Price: USD $2.2792
≥1 USD $2.2792
≥10 USD $1.86032
≥100 USD $1.509728
≥500 USD $1.404304
≥1000 USD $1.33408
Inventory: 696
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-8
Number of Pins 8
Technical
Operating Temperature -55°C~127°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature One-Shot, Shutdown Mode
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Sensors
Voltage - Supply 2.7V~5.5V
Base Part Number TMP442
Body Breadth 1.6 mm
Output Voltage 400mV
Output Type SMBus
Power Supplies 3/5V
Interface I2C, SMBus
Termination Type SOLDER
Operating Supply Current 700μA
Nominal Supply Current 700μA
Output Current 6mA
Number of Bits 12
Quiescent Current 700μA
Resolution 11 b
Sensor Type Digital, Local/Remote
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL
Test Condition 0°C ~ 100°C (-40°C ~ 125°C)
Max Supply Voltage (DC) 5.5V
Min Supply Voltage (DC) 2.7V
Accuracy - Highest (Lowest) ±1°C (±2.5°C)
Sensing Temperature - Local -40°C~125°C
Accuracy-Max 1 Cel
Sensing Temperature - Remote -64°C~191°C
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.63mm
Thickness 1.1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
