TMP442ADCNT
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-8
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
IC, TEMP SENSOR, 8SOT23
PDF
/
Buying Options
Total Price: USD $2.28
Unit Price: USD $2.2792
≥1 USD $2.2792
≥10 USD $1.86032
≥100 USD $1.509728
≥500 USD $1.404304
≥1000 USD $1.33408
Inventory: 1187
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.1mm
Width 1.63mm
Length 2.9mm
Height 1.45mm
Technical
Sensing Temperature - Remote -64°C~191°C
Accuracy-Max 1 Cel
Sensing Temperature - Local -40°C~125°C
Accuracy - Highest (Lowest) ±1°C (±2.5°C)
Min Supply Voltage (DC) 2.7V
Max Supply Voltage (DC) 5.5V
Test Condition 0°C ~ 100°C (-40°C ~ 125°C)
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL
Sensor Type Digital, Local/Remote
Resolution 11 b
Quiescent Current 700μA
Number of Bits 12
Output Current 6mA
Nominal Supply Current 700μA
Operating Supply Current 35μA
Termination Type SOLDER
Interface I2C, SMBus
Power Supplies 3/5V
Output Type SMBus
Output Voltage 150mV
Body Breadth 1.6 mm
Base Part Number TMP442
Voltage - Supply 2.7V~5.5V
Subcategory Other Sensors
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature One-Shot, Shutdown Mode
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -55°C~127°C
Physical
Number of Pins 8
Package / Case SOT-23-8
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
