TMP432ADGST
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
TEXAS INSTRUMENTS TMP432ADGST Temperature Sensor IC, Digital,1C, -40 C, +125 C, MSOP, 10 Pins
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.54
≥1 USD $1.54
≥10 USD $1.38512
≥100 USD $1.306624
≥500 USD $1.1132
Inventory: 1046
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Number of Pins 10
Technical
Operating Temperature -55°C~127°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature One-Shot, Output Switch, Programmable Limit, Programmable Resolution, Shutdown Mode
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Base Part Number TMP432
Pin Count 10
Output Type SMBus
Number of Channels 2
Interface I2C, SMBus
Analog IC - Other Type ANALOG CIRCUIT
Operating Supply Current 10mA
Nominal Supply Current 10mA
Output Current 6mA
Number of Bits 12
Quiescent Current 35μA
Resolution 11 b
Sensor Type Digital, Local/Remote
Test Condition 0°C ~ 100°C (-40°C ~ 125°C)
Max Supply Voltage (DC) 5.5V
Min Supply Voltage (DC) 2.7V
Accuracy - Highest (Lowest) ±1°C (±2.5°C)
Sensing Temperature - Local -40°C~125°C
Sensing Temperature - Remote -64°C~191°C
Dimensions
Height 1.07mm
Length 3mm
Width 3mm
Thickness 1.02mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
