TMP421YZDR
RoHS
RoHS compliant
RoHS compliantPackage 8-UFBGA, DSBGA
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
Board Mount Temperature Sensors +/-1degC Remote & Local Temp Sensor
PDF
/
Buying Options
Total Price: USD $1.73
Unit Price: USD $1.7336
≥1 USD $1.7336
≥10 USD $1.33672
≥100 USD $1.113728
≥500 USD $1.089088
≥1000 USD $0.990088
≥3000 USD $0.86636
Inventory: 1120
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 650μm
Width 2.3mm
Length 1.3mm
Height 1mm
Technical
Sensing Temperature - Remote -64°C~191°C
Accuracy-Max 1 Cel
Sensing Temperature - Local -40°C~125°C
Accuracy - Highest (Lowest) ±1.5°C (±2.5°C)
Test Condition 15°C ~ 85°C (-40°C ~ 125°C)
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL
Sensor Type Digital, Local/Remote
Resolution 11 b
Quiescent Current 400μA
Number of Bits 12
Termination Type SOLDER
Interface I2C, SMBus
Power Supplies 3/5V
Output Type SMBus
Body Breadth 0.902 mm
Base Part Number TMP421
Voltage - Supply 2.7V~5.5V
Subcategory Other Sensors
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature One-Shot, Output Switch, Programmable Limit, Shutdown Mode
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-UFBGA, DSBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 16 Weeks
