TMP235A2DCKT
RoHS
RoHS compliant
RoHS compliantPackage 5-TSSOP, SC-70-5, SOT-353
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
SENSOR ANALOG -40C-150C SC70-5
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2056
≥1 USD $1.2056
≥10 USD $0.90376
≥100 USD $0.723008
≥500 USD $0.662904
Inventory: 779
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 5-TSSOP, SC-70-5, SOT-353
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -50°C~150°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature SHORT CIRCUIT PROTECTION
Technology CMOS
Voltage - Supply 2.3V~5.5V
Base Part Number TMP235
Output Type Analog Voltage
Interface Analog
Termination Type SOLDER
Resolution 10mV/°C
Sensor Type Analog, Local
Test Condition 0°C ~ 70°C (-40°C ~ 150°C)
Housing PLASTIC
Accuracy - Highest (Lowest) ±0.5°C
Sensing Temperature - Local -40°C~150°C
Accuracy-Max 2 Cel
R0-Nom 20 Ω
Dimensions
Height 1.1mm
Length 2mm
Width 1.25mm
Thickness 900μm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
