TMP103AYFFT
RoHS
RoHS compliant
RoHS compliantPackage 4-UFBGA, DSBGA
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
Tape & Reel (TR) I2C/SMBus One-Shot Shutdown Mode 8 Digital, Local Temperature Sensor 0.76mm 85muA 1.4V~3.6V ±2C (±3C)
PDF
/
Buying Options
Total Price: USD $1.69
Unit Price: USD $1.6896
≥1 USD $1.6896
≥10 USD $1.30504
≥100 USD $1.088032
≥500 USD $1.063744
≥1000 USD $0.967032
Inventory: 1098
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.2mm
Width 1mm
Length 1.2mm
Height 625μm
Technical
Accuracy-Max 3 Cel
Sensing Temperature - Local -40°C~125°C
Accuracy - Highest (Lowest) ±2°C (±3°C)
Min Supply Voltage (DC) 1.4V
Max Supply Voltage (DC) 3.6V
Test Condition -10°C ~ 100°C (-40°C ~ 125°C)
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL
Sensor Type Digital, Local
Resolution 7 b
Quiescent Current 1.5μA
Number of Bits 8
Output Current 2mA
Nominal Supply Current 85μA
Operating Supply Current 3μA
Termination Type SOLDER
Interface 2-Wire, I2C, SMBus
Power Supplies 1.5/3.3V
Output Type I2C/SMBus
Body Breadth 0.76 mm
Base Part Number TMP103
Voltage - Supply 1.4V~3.6V
Subcategory Other Sensors/Transducers
Additional Feature SEATED HGT-MAX
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature One-Shot, Shutdown Mode
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C
Physical
Number of Pins 4
Package / Case 4-UFBGA, DSBGA
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper, Silver, Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
