LM71CIMF
RoHS
/
Package SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
SENSOR DIGITAL -40C-150C SOT23-5
PDF
/
Buying Options
Total Price: USD $1.42
Unit Price: USD $1.4168
≥1 USD $1.4168
Inventory: 248
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.2mm
Width 1.6mm
Length 2.9mm
Height 1.45mm
Technical
Output Interface Type 3-WIRE INTERFACE
Accuracy-Max 3 Cel
Sensing Temperature - Local -40°C~150°C
Accuracy - Highest (Lowest) 1.5°C (-2°C, 3°C)
Housing PLASTIC
Min Supply Voltage (DC) 2.6V
Max Supply Voltage (DC) 5.5V
Test Condition -10°C ~ 65°C (-40°C ~ 150°C)
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL
Sensor Type Digital, Local
Resolution 13 b
Quiescent Current 550μA
Number of Bits 14
Nominal Supply Current 300μA
Operating Supply Current 300μA
Power Supplies 3/3.3V
Max Output Current 550μA
Output Type SPI
Output Voltage 2.4V
Base Part Number LM71
Voltage - Supply 2.65V~5.5V
Technology CMOS
Subcategory Other Sensors/Transducers
Terminal Finish Tin/Lead (Sn/Pb)
Temperature Coefficient POSITIVE ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Feature Shutdown Mode
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 1 week ago)
