STTS751-0WB3F
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
SENSOR TEMPERATURE SMBUS SOT23-6
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.2445
≥1 USD $1.2445
≥10 USD $1.02125
≥100 USD $0.9899
≥500 USD $0.9576
≥1000 USD $0.9253
Inventory: 6005
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6
Number of Pins 6
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature One-Shot, Output Switch, Programmable Limit, Programmable Resolution, Standby Mode
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Voltage - Supply 2.25V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.95mm
Base Part Number STTS751
Pin Count 6
Output Type SMBus
Max Output Current 20mA
Interface 2-Wire, I2C, SMBus, Serial
Analog IC - Other Type TEMPERATURE SENSOR
Operating Supply Current 50μA
Output Current 20mA
Resolution 11 b
Sensor Type Digital, Local
Test Condition 0°C ~ 85°C (-40°C ~ 125°C)
Max Supply Voltage (DC) 3.6V
Min Supply Voltage (DC) 2V
Accuracy - Highest (Lowest) ±1.5°C (±2.5°C)
Sensing Temperature - Local -40°C~125°C
Dimensions
Height Seated (Max) 1.45mm
Length 2.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
