STLM75DS2F
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
STLM75 Series 5.5 V Digital Temperature Sensor and Thermal Watchdog - MSOP-8
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5377
≥1 USD $0.5377
≥10 USD $0.4408
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
Inventory: 15981
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height 850μm
Technical
Accuracy-Max 3 Cel
Sensing Temperature - Local -55°C~125°C
Accuracy - Highest (Lowest) ±2°C (±3°C)
Housing PLASTIC
Min Supply Voltage (DC) 2.7V
Max Supply Voltage (DC) 5.5V
Test Condition -25°C ~ 100°C (-55°C ~ 125°C)
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL
Sensor Type Digital, Local
Resolution 8 b
Number of Bits 9
Output Current 10mA
Operating Supply Current 125μA
Termination Type SOLDER
Interface 2-Wire, I2C, SMBus, Serial
Power Supplies 3/5V
Output Type I2C/SMBus
Base Part Number STLM75
Voltage - Supply 2.7V~5.5V
Technology CMOS
Subcategory Other Sensors
Additional Feature CMOS COMPATIBLE, THERMAL WATCHDOG
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Output Switch, Programmable Limit, Shutdown Mode, Standby Mode
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 16 Weeks
