MCP9808-E/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
MICROCHIP - MCP9808-E/MS - Temperature Sensor IC, Digital, 0.25 C, -40 C, +125 C, MSOP, 8 RoHS Compliant: Yes
PDF
/
Buying Options
Total Price: USD $1.23
Unit Price: USD $1.232
≥1 USD $1.232
≥10 USD $1.0296
≥100 USD $0.924
Inventory: 10911
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2004
JESD-609 Code e3
Feature Output Switch, Programmable Limit, Programmable Resolution, Shutdown Mode
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Voltage - Supply 2.7V~5.5V
Output Type I2C/SMBus
Interface 2-Wire, I2C, SMBus, Serial
Termination Type SOLDER
Nominal Supply Current 200μA
Output Current 200μA
Number of Bits 16
Resolution 10 b
Sensor Type Digital, Local
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL
Test Condition -20°C ~ 100°C (-40°C ~ 125°C)
Max Supply Voltage (DC) 5.5V
Min Supply Voltage (DC) 2.7V
Housing PLASTIC
Accuracy - Highest (Lowest) ±0.5°C (±1°C)
Sensing Temperature - Local -40°C~125°C
Accuracy-Max 1 Cel
Dimensions
Height 950μm
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
