MCP9800A5T-M/OTG
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Sensors, Transducers / Temperature Sensors - Analog and Digital Output
Description
SENSOR TEMP I2C/SMBUS SOT23-5
PDF
/
Inventory: 2034
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Accuracy-Max 3 Cel
Sensing Temperature - Local -55°C~125°C
Accuracy - Highest (Lowest) ±1°C (±3°C)
Housing PLASTIC
Min Supply Voltage (DC) 2.7V
Max Supply Voltage (DC) 5.5V
Test Condition -10°C ~ 85°C (-55°C ~ 125°C)
Sensors/Transducers Type TEMPERATURE SENSOR,SWITCH/DIGITAL OUTPUT,SERIAL
Sensor Type Digital, Local
Resolution 11 b
Number of Bits 12
Output Current 200μA
Operating Supply Current 400μA
Termination Type SOLDER
Interface 2-Wire, I2C, SMBus
Output Type I2C/SMBus
Body Breadth 1.63 mm
Base Part Number MCP9800
Voltage - Supply 2.7V~5.5V
Subcategory Other Sensors
Terminal Finish Matte Tin (Sn)
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature One-Shot, Output Switch, Programmable Limit, Programmable Resolution, Shutdown Mode
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 5
Surface Mount YES
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
