Technical Details
Physical
Contact Material COPPER ALLOY
Mounting Type BOARD
Insulation Material POLYCYCLOHEXYLENE TEREPHTHALATE
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Technical
JESD-609 Code e3
Pbfree Code icon-pbfree yes
Connector Type BOARD CONNECTOR
Number of Rows 2
Additional Feature 3M, LOW PROFILE, POLARIZED
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating GOLD (30) OVER NICKEL (100)
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 20
Terminal Pitch 2.54mm
Reach Compliance Code compliant
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.288 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.338 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.4 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.1 inch
Body/Shell Style RECEPTACLE
Termination Type SURFACE MOUNT
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1400VAC V
PCB Contact Row Spacing 6.858 mm
Contact Finish Termination Matte Tin (Sn) - with Nickel (Ni) barrier
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.1 inch
Dimensions
Plating Thickness 30u inch
Compliance
RoHS Status RoHS Compliant
