EVQ-QWM01W image
Favorite
EVQ-QWM01W image
Favorite
RoHS
/
Package SMD/SMT
Category Switches / Tactile Switches
Description Standard EVQQW Surface Mount Top Actuated Tactile Switch 2.00mm 20mA 0.02A @ 15VDC 130gf
PDF
/
Inventory: 7410
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Technical

Actuator Height off PCB, Vertical 2.00mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.02A @ 15VDC
Outline 6.20mm x 6.20mm
Actuator Orientation Top Actuated
Illumination Type Non-Illuminated
Operating Force 130gf
Contact Current Rating 20mA
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style J Lead
Orientation Vertical
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Grounding Pin
Series EVQQW
Published 2001
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C

Physical

Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
