EVQ-QWK03W
RoHS
/
Package SMD/SMT
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.02A 15V
PDF
/
Inventory: 8648
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Published 2001
Series EVQQW
Feature Grounding Pin
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Additional Feature CONTACT BOUNCE TIME-MAX: 3 (ON)
HTS Code 8536.50.90.40
Packing Method BOX; TAPE AND REEL
Orientation Vertical
Reach Compliance Code unknown
Termination Style J Lead
Body Length or Diameter 6.2mm
Body Breadth 6.2 mm
Actuator Type Standard
Contact Bounce Time-Max 8ms
Number of Switches 1
Actuator Height off PCB, Vertical 3.10mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.02A @ 15VDC
Outline 6.20mm x 6.20mm
Contact (DC) Max Rating R Load .02A@15VDC
Actuator Orientation Top Actuated
Operating Force 260gf
Contact Current Rating 20mA
Switch Type KEYPAD SWITCH
Mechanical Life 10,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 10000 Cycle(s)
Contact Current(DC)-Max 0.02A
Switch Function Off-Mom
Circuit SPST-NO
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Body Height 2mm
