EVQ-QJD05B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACT SPST-NO 0.005A 12V
PDF
/
Inventory: 5200
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Body Height 3.8mm
Technical
Contact Bounce Time-Max 10ms
Number of Switches 1
Actuator Height off PCB, Vertical 5.50mm
Switch Travel 1.20mm
Contact Rating @ Voltage 0.005A @ 12VDC
Outline 8.00mm x 8.00mm
Contact (DC) Max Rating R Load .005A@12VDC
Actuator Orientation Top Actuated
Operating Force 250gf
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Electrical Life 100000 Cycle(s)
Contact Current(DC)-Max 0.005A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 8 mm
Body Length or Diameter 8mm
Termination Style PC Pin
Reach Compliance Code unknown
Packing Method BOX; TAPE AND REEL
HTS Code 8536.50.90.40
Terminal Finish GOLD/SILVER
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series EVQQJ
Published 2011
Packaging Tape & Box (TB)
Operating Temperature -20°C~70°C
Physical
Surface Mount NO
Mounting Type Through Hole
