EVQ-PSC02K
RoHS
/
Package /
Category Switches / Tactile Switches
Description
Switch Tactile N.O. SPST Button J-Bend 0.05A 12VDC 1.6N SMD T/R
PDF
/
Inventory: 6524
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Actuator Length 1.3mm
Body Height 1.8mm
Length 7.4mm
Technical
Contact Bounce Time-Max 10ms
Number of Switches 1
Switch Travel 0.30mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 4.60mm x 6.10mm
Contact (DC) Max Rating R Load .05A@12VDC
Actuator Orientation Side Actuated
Illumination Type Illuminated, Non-Illuminated
Operating Force 160gf
Contact Current Rating 50mA
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Max Voltage Rating (DC) 12V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 cycles
Max Current Rating 50mA
Contact Current(DC)-Max 0.05A
Contact Resistance 500mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style J Lead
Current Rating 50mA
Depth 4.6mm
Orientation Right Angle
Packing Method BOX; TAPE AND REEL
Voltage - Rated DC 12V
HTS Code 8536.50.90.40
Color Black
ECCN Code EAR99
Termination J-Bend
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series EVQPS
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Silver
Supply Chain
Factory Lead Time 6 Weeks
