EVQ-PPFA25
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Inventory: 4360
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 0.028 inch
Body Height 1.8mm
Technical
Contact Bounce Time-Max 10ms
Number of Switches 1
Actuator Height off PCB, Vertical 2.50mm
Solderability WAVE
Actuator Travel 0.254 mm
Switch Travel 0.25mm
Contact Function OFF-(ON)
Actuator Color BLACK
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 3.50mm
Contact (DC) Max Rating R Load .05A@12VDC
Actuator Orientation Top Actuated
Contact Timing SNAP ACTION
Operating Force 160gf
Switch Type KEYPAD SWITCH
Mechanical Life 50,000 Cycles
Illumination Non-Illuminated
Electrical Life 50000 Cycle(s)
Dielectric Withstanding Voltage 250VAC V
Contact Current(DC)-Max 0.05A
Insulation Resistance 100000000Ohm
Contact Resistance 0.1mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 3.7 mm
Body Length or Diameter 6mm
Termination Style Gull Wing
Reach Compliance Code unknown
Ingress Protection Dust Proof
Packing Method BOX; TAPE AND REEL
HTS Code 8536.50.90.40
Additional Feature TAPE AND REEL PACKAGING
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series EVQPP
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Mounting Type Surface Mount
