EVQ-PF208K
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.02A 15V
PDF
/
Inventory: 9496
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Plating Gold, Silver
Mount Through Hole
Mounting Type Through Hole, Right Angle
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 2010
Series EVQPF
JESD-609 Code e4
Pbfree Code yes
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
ECCN Code EAR99
Number of Positions 2
Terminal Finish GOLD/SILVER
Color Black
HTS Code 8536.50.90.40
Voltage - Rated DC 15V
Packing Method BAG; BOX
Orientation Right Angle
Depth 12.35mm
Current Rating 20mA
Termination Style PC Pin
Body Breadth 7.5 mm
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 50mOhm
Max Current Rating 20mA
Electrical Life 100000 cycles
Throw Configuration SPST
Illumination Non-Illuminated
Max Voltage Rating (DC) 15V
Mechanical Life 100,000 Cycles
Switch Type KEYPAD SWITCH
Contact Current Rating 20mA
Operating Force 160gf
Illumination Type Illuminated, Non-Illuminated
Actuator Orientation Side Actuated
Outline 7.50mm x 7.10mm
Contact Rating @ Voltage 0.02A @ 15VDC
Switch Travel 0.25mm
Number of Switches 1
Contact Bounce Time-Max 8 ms
Dimensions
Height 8.35mm
Length 6.2mm
Width 4mm
Actuator Length 8.35mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
