EVQ-PC005K
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Switches / Tactile Switches
Description
Switch,Light Touch;5N type;side push;1.0N;Panasert;20mm H0.
PDF
/
Inventory: 5257
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Actuator Length, Right Angle 4.75mm
Actuator Length 2.3mm
Body Height 7.1mm
Technical
Contact Bounce Time-Max 8ms
Number of Switches 1
Switch Travel 0.25mm
Contact Rating @ Voltage 0.02A @ 15VDC
Outline 7.50mm x 6.95mm
Contact (DC) Max Rating R Load .02A@15VDC
Actuator Orientation Side Actuated
Illumination Type Illuminated, Non-Illuminated
Operating Force 100gf
Contact Current Rating 20mA
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Max Voltage Rating (DC) 15V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 cycles
Contact Current(DC)-Max 0.02A
Contact Resistance 50mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 6.95 mm
Body Length or Diameter 7.5mm
Termination Style PC Pin
Current Rating 20mA
Orientation Right Angle
Packing Method BOX; TAPE AND REEL
Voltage - Rated DC 15V
HTS Code 8536.50.90.40
Terminal Finish GOLD/SILVER
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Pbfree Code yes
JESD-609 Code e4
Series EVQPC
Published 2011
Packaging Tape & Box (TB)
Operating Temperature -20°C~70°C
Physical
Package / Case Radial
Mounting Type Through Hole, Right Angle
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
