EVQ-P4K03Q
RoHS
/
Package /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.02A 15V
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.39864
≥100 USD $0.352704
≥500 USD $0.352088
Inventory: 518
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Actuator Length, Right Angle 2.50mm
Body Height 2.55mm
Technical
Contact Bounce Time-Max 10ms
Number of Switches 1
Switch Travel 0.70mm
Contact Rating @ Voltage 0.02A @ 15VDC
Outline 6.20mm x 2.55mm
Contact (DC) Max Rating R Load .02A@15VDC
Actuator Orientation Side Actuated
Operating Force 350gf
Contact Current Rating 20mA
Switch Type KEYPAD SWITCH
Mechanical Life 500,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 500000 Cycle(s)
Contact Current(DC)-Max 0.02A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 3.5 mm
Body Length or Diameter 6.2mm
Termination Style SMD (SMT) Tab
Current Rating 20mA
Reach Compliance Code unknown
Orientation Right Angle
Packing Method BOX; TAPE AND REEL
Voltage - Rated DC 15V
HTS Code 8536.50.90.40
Terminal Finish GOLD/SILVER
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series EVQP4
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Mounting Type Edge Mount, Right Angle
Mount Edge
