EVQ-P2602M
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.02A 15V
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.6072
≥1 USD $0.6072
≥10 USD $0.5852
≥100 USD $0.5632
≥500 USD $0.487432
≥1000 USD $0.444083
≥3000 USD $0.411594
Inventory: 5920
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2010
Series EVQP2
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish GOLD/SILVER
HTS Code 8536.50.90.40
Packing Method BOX; TAPE AND REEL
Termination Style J Lead
Body Length or Diameter 4.7mm
Body Breadth 3.5 mm
Actuator Type Rectangular Button
Circuit SPST-NO
Switch Function Off-Mom
Contact Current(DC)-Max 0.02A
Electrical Life 200000 Cycle(s)
Illumination Non-Illuminated
Mechanical Life 200,000 Cycles
Switch Type KEYPAD SWITCH
Operating Force 350gf
Actuator Orientation Top Actuated
Contact (DC) Max Rating R Load .02A@15VDC
Outline 4.70mm x 3.50mm
Contact Rating @ Voltage 0.02A @ 15VDC
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 2.10mm
Number of Switches 1
Contact Bounce Time-Max 10ms
Dimensions
Body Height 1.65mm
Compliance
RoHS Status RoHS Compliant
