EVQ-P2002M
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.02A 15V
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.6248
≥1 USD $0.6248
≥10 USD $0.59928
≥100 USD $0.576224
≥500 USD $0.500104
≥1000 USD $0.456298
≥3000 USD $0.424054
Inventory: 1376
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2012
Series EVQP2
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination J-Bend
ECCN Code EAR99
Number of Positions 2
Terminal Finish GOLD/SILVER
HTS Code 8536.50.90.40
Voltage - Rated DC 15V
Packing Method BOX; TAPE AND REEL
Orientation Straight
Current Rating 20mA
Termination Style J Lead
Body Length or Diameter 4.7mm
Body Breadth 3.5 mm
Actuator Type Rectangular Button
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 100mOhm
Electrical Life 1e+06 cycles
Throw Configuration SPST
Illumination Non-Illuminated
Max Voltage Rating (DC) 15V
Mechanical Life 1,000,000 Cycles
Switch Type KEYPAD SWITCH
Contact Current Rating 20mA
Operating Force 100gf
Illumination Type Illuminated, Non-Illuminated
Actuator Orientation Top Actuated
Outline 4.70mm x 3.50mm
Contact Rating @ Voltage 0.02A @ 15VDC
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 2.10mm
Number of Switches 1
Contact Bounce Time-Max 10 ms
Dimensions
Height 2.1mm
Actuator Length 450μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
