EVQ-9P701P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.25696
≥100 USD $0.243584
≥500 USD $0.220528
≥1000 USD $0.201027
≥3000 USD $0.186859
Inventory: 20890
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 1.55mm
Technical
Life (Cycles) 100000 cycles
Switch Travel 0.20mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 4.70mm x 2.90mm
Actuator Orientation Side Actuated
Operating Force 160gf
Contact Current Rating 50mA
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Contact Resistance 500mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Rectangular Button
Termination Style Gull Wing
Voltage - Rated DC 12V
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series EVQ9P7
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Manufacturer Package Identifier EVQ-9P701P
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Gold
Supply Chain
Factory Lead Time 8 Weeks
