EVQ-21309K
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Switches / Tactile Switches
Description
Switch Tactile N.O. SPST Round Button PC Pins 0.02A 15VDC 1N Thru-Hole Radial T/R
PDF
/
Inventory: 6251
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Actuator Length 6.1mm
Width 6mm
Length 6mm
Height 9.5mm
Technical
Contact Bounce Time-Max 8ms
Number of Switches 1
Actuator Height off PCB, Vertical 9.50mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.02A @ 15VDC
Outline 6.00mm x 6.00mm
Contact (DC) Max Rating R Load .02A@15VDC
Actuator Orientation Top Actuated
Illumination Type Illuminated, Non-Illuminated
Operating Force 100gf
Contact Current Rating 20mA
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Max Voltage Rating (DC) 15V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 cycles
Max Current Rating 20mA
Contact Current(DC)-Max 0.02A
Contact Resistance 50mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style PC Pin
Current Rating 20mA
Depth 6mm
Orientation Straight
Packing Method BOX; TAPE AND REEL
Voltage - Rated DC 15V
HTS Code 8536.50.90.40
Color Black
Terminal Finish GOLD/SILVER
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Pbfree Code yes
JESD-609 Code e4
Series EVQ2
Published 2011
Packaging Tape & Box (TB)
Operating Temperature -20°C~70°C
Physical
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold, Silver
Supply Chain
Factory Lead Time 12 Weeks
