EVQ-11L09K
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Switches / Tactile Switches
Description
PANASONIC EVQ-11L09K SWITCH, TACTILE, SPST-NO, 20mA, 15VDC
PDF
/
Inventory: 1769
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Box (TB)
Published 2011
Series EVQ11
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 70°C
Min Operating Temperature -20°C
Voltage - Rated DC 15V
Orientation Straight
Current Rating 20mA
Termination Style PC Pin
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 50mOhm
Electrical Life 100000 cycles
Throw Configuration SPST
Illumination Non-Illuminated
Max Voltage Rating (DC) 15V
Mechanical Life 100,000 Cycles
Contact Current Rating 20mA
Operating Force 160gf
Illumination Type Illuminated, Non-Illuminated
Actuator Orientation Top Actuated
Outline 6.00mm x 6.00mm
Contact Rating @ Voltage 0.02A @ 15VDC
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 9.50mm
Dimensions
Actuator Length 5.6mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
