95C06E4T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Switch Tactile N.O. SPST Round Button PC Pins 0.05A 12VDC 2.55N Thru-Hole Bulk
PDF
/
Inventory: 9971
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number of Switches 1
Actuator Height off PCB, Vertical 13.00mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.20mm x 6.20mm
Contact (DC) Max Rating R Load .05A@12VDC
Actuator Orientation Top Actuated
Operating Force 260gf
Switch Type KEYPAD SWITCH
Mechanical Life 500,000 Cycles
Max Voltage Rating (DC) 12V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 500000 Cycle(s)
Max Current Rating 50mA
Contact Current(DC)-Max 0.05A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style PC Pin
Depth 7.9mm
Orientation Straight
Voltage - Rated DC 12V
HTS Code 8536.50.90.40
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Tactile Feedback
JESD-609 Code e4
Series 95C
Published 2008
Packaging Bulk
Operating Temperature -25°C~70°C
Dimensions
Length 6.2mm
Body Height 3.5mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Actuator Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Contact Material Stainless Steel
Supply Chain
Factory Lead Time 16 Weeks
