95C06E2GWT
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Tactile Switches
Description
Standard 95C Surface Mount Top Actuated Tactile Switch 13.00mm 0.05A 12V 0.05A @ 12VDC
PDF
/
Inventory: 8617
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Stainless Steel
Contact Plating Silver
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -25°C~70°C
Packaging Tube
Published 2008
Series 95C
JESD-609 Code e4
Feature Tactile Feedback
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
HTS Code 8536.50.90.40
Voltage - Rated DC 12V
Orientation Straight
Depth 9mm
Termination Style Gull Wing
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Current(DC)-Max 0.05A
Max Current Rating 50mA
Electrical Life 1000000 Cycle(s)
Throw Configuration SPST
Illumination Non-Illuminated
Max Voltage Rating (DC) 12V
Mechanical Life 1,000,000 Cycles
Switch Type KEYPAD SWITCH
Operating Force 100gf
Actuator Orientation Top Actuated
Contact (DC) Max Rating R Load .05A@12VDC
Outline 6.20mm x 6.20mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 13.00mm
Number of Switches 1
Dimensions
Length 6.2mm
Body Height 3.5mm
Compliance
RoHS Status RoHS Compliant
