95C06C2GWRT
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Tactile Switches
Description
Switch Tactile N.O. SPST Round Button Gull Wing 0.05A 12VDC 0.98N SMD T/R
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.368925
≥1 USD $0.368925
Inventory: 7618
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 6.2mm
Technical
Actuator Height off PCB, Vertical 7.00mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.20mm x 6.20mm
Actuator Orientation Top Actuated
Illumination Type Non-Illuminated
Operating Force 100gf
Mechanical Life 1,000,000 Cycles
Max Voltage Rating (DC) 12V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 1e+06 cycles
Max Current Rating 50mA
Contact Resistance 100mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style Gull Wing
Depth 9mm
Orientation Straight
Voltage - Rated DC 12V
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tactile Feedback
Series 95C
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -25°C~70°C
Physical
Actuator Material Polyamide (PA), Nylon
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Contact Material Stainless Steel
Supply Chain
Factory Lead Time 16 Weeks
