95C04B3GWT
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Tactile Switches
Description
Switch Tactile N.O. SPST Rectangular Button Gull Wing 0.05A 12VDC 1.57N SMD Tube
PDF
/
Inventory: 9059
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 7.2mm
Technical
Number of Switches 1
Actuator Height off PCB, Vertical 5.00mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 3.50mm
Contact (DC) Max Rating R Load .05A@12VDC
Actuator Orientation Top Actuated
Operating Force 160gf
Switch Type KEYPAD SWITCH
Mechanical Life 50,000 Cycles
Max Voltage Rating (DC) 12V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 50000 Cycle(s)
Max Current Rating 50mA
Contact Current(DC)-Max 0.05A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Rectangular Button
Termination Style Gull Wing
Depth 3.5mm
Orientation Straight
Voltage - Rated DC 12V
HTS Code 8536.50.90.40
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Tactile Feedback
JESD-609 Code e4
Series 95C
Published 2008
Packaging Tube
Operating Temperature -25°C~70°C
Physical
Actuator Material Polyamide (PA), Nylon
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Contact Material Stainless Steel
Supply Chain
Factory Lead Time 16 Weeks
