TLE1105BF160Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Tactile Switches 6.0X9.5MM 160G W/GND
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
≥10 USD $0.31944
≥100 USD $0.300608
≥500 USD $0.261096
≥1000 USD $0.236826
≥3000 USD $0.22029
Inventory: 4622
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Actuator Height off PCB, Vertical 9.50mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 6.00mm
Actuator Orientation Top Actuated
Operating Force 160gf
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style PC Pin
Current Rating 50mA
Voltage - Rated DC 12V
Color Black
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Grounding Pin
Series TL1105
Published 2002
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
Actuator Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Supply Chain
Factory Lead Time 11 Weeks
