TL6700AF260QJ

E-Switch
RoHS
RoHS RoHS compliant
Package /
Category Switches / Tactile Switches
Description SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.602301
≥1 USD $0.602301
≥10 USD $0.568207
≥100 USD $0.536048
≥500 USD $0.505696
≥1000 USD $0.477082
Inventory: 1250
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Body Height 3.4mm

Technical

Number of Switches 1
Actuator Height off PCB, Vertical 3.40mm
Switch Travel 0.35mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.90mm x 6.20mm
Contact (DC) Max Rating R Load .05A@12VDC
Actuator Orientation Top Actuated
Operating Force 260gf
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 Cycle(s)
Sealing WATER PROOF
Contact Current(DC)-Max 0.05A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 6.2 mm
Body Length or Diameter 6.9mm
Termination Style J Lead
Current Rating 50mA
Voltage - Rated DC 12V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Process Sealed
Series TL6700
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C

Physical

Actuator Material Silicon Rubber
Mounting Type Surface Mount
Mount Sealed, Surface Mount
Contact Plating Silver

Supply Chain

Factory Lead Time 11 Weeks
