TL6120AF500QG

E-Switch
RoHS
RoHS RoHS compliant
Package SMD/SMT
Category Switches / Tactile Switches
Description Tactile Switches Process Sealed SMT SPST 0.05A 12V
PDF
/
Inventory: 3618
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Contact Plating Silver
Mount Sealed, Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Actuator Material Polyamide (PA), Nylon

Technical

Operating Temperature -40°C~85°C
Contact Bounce Time-Max 5ms
Number of Switches 1
Actuator Height off PCB, Vertical 4.70mm
Switch Travel 0.50mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 7.40mm x 7.40mm
Contact (DC) Max Rating R Load .02A@50VDC
Actuator Orientation Top Actuated
Operating Force 500gf
Switch Type KEYPAD SWITCH
Mechanical Life 200,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 30000 Cycle(s)
Contact Current(DC)-Max 0.02A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 7.2 mm
Body Length or Diameter 7.2mm
Termination Style Gull Wing
Current Rating 50mA
Voltage - Rated DC 12V
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series TL6120
Published 2006
Packaging Tape & Reel (TR)

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Body Height 2.7mm
