TL59F260Q
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Switches / Tactile Switches
Description
Tactile Switches Thruhole Radial lead SPST-NO 0.05A 12V
PDF
/
Buying Options
Total Price: USD $0.24
Unit Price: USD $0.239527
≥1 USD $0.239527
≥10 USD $0.225971
≥100 USD $0.213174
≥500 USD $0.201114
≥1000 USD $0.189734
Inventory: 6867
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Actuator Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Box (TB)
Published 2001
Series TL59
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Voltage - Rated DC 12V
Current Rating 50mA
Termination Style PC Pin
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Throw Configuration SPST
Illumination Non-Illuminated
Mechanical Life 100,000 Cycles
Switch Type KEYPAD SWITCH
Operating Force 260gf
Actuator Orientation Top Actuated
Outline 6.20mm x 6.20mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 4.30mm
Compliance
RoHS Status ROHS3 Compliant
