TL53BF100Q
RoHS
/
Package /
Category Switches / Tactile Switches
Description
Tactile Switches Double Stacked Tact SPST X 2 0.05A 12V
PDF
/
Inventory: 8374
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Actuator Length, Right Angle 5.85mm
Technical
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 8.40mm x 10.50mm
Actuator Orientation Side Actuated
Operating Force 100gf
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Switch Function Off-Mom
Circuit SPST x 2
Actuator Type Dual
Termination Style PC Pin
Current Rating 50mA
Voltage - Rated DC 12V
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series TL53
Published 2006
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
Actuator Material Acetal
Mounting Type Through Hole, Right Angle
Mount Through Hole
