TL3305CF260QG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Standard TL3305 Surface Mount Top Actuated Tactile Switch 7.00mm 0.05A 0.05A @ 12VDC 260gf
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.2288
≥1 USD $0.2288
≥10 USD $0.2244
≥100 USD $0.212608
≥500 USD $0.192544
≥1000 USD $0.175542
≥3000 USD $0.163152
Inventory: 18358
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Published 2016
Series TL3305
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
HTS Code 8536.50.90.40
Packing Method TR
Termination Style Gull Wing
Body Length or Diameter 4.5mm
Body Breadth 4.5 mm
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Current(DC)-Max 0.05A
Electrical Life 200000 Cycle(s)
Throw Configuration SPST
Illumination Non-Illuminated
Mechanical Life 200,000 Cycles
Switch Type KEYPAD SWITCH
Operating Force 260gf
Actuator Orientation Top Actuated
Contact (DC) Max Rating R Load .05A@12VDC
Outline 4.50mm x 4.50mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.20mm
Actuator Height off PCB, Vertical 7.00mm
Number of Switches 1
Dimensions
Body Height 6.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
