TL3304AF160QJ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Tactile Switches SPST 6.2mmSQ J-LEAD
PDF
/
Buying Options
Total Price: USD $0.71
Unit Price: USD $0.7128
≥1 USD $0.7128
≥10 USD $0.68904
≥100 USD $0.662112
≥500 USD $0.574728
≥1000 USD $0.524445
≥3000 USD $0.487344
Inventory: 8696
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 800μm
Body Height 2.5908mm
Technical
Actuator Height off PCB, Vertical 3.40mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 50VDC
Outline 6.20mm x 6.20mm
Contact (DC) Max Rating R Load 0.05A@50VDC
Actuator Orientation Top Actuated
Contact Timing SNAP ACTION
Operating Force 160gf
Switch Type PUSHBUTTON SWITCH
Mechanical Life 100,000 Cycles
Max Voltage Rating (DC) 12V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 cycles
Dielectric Withstanding Voltage 1000VRMS V
Contact Current(DC)-Max 0.05A
Insulation Resistance 100000000Ohm
Contact Resistance 100mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 6.1976 mm
Body Length or Diameter 6.1976mm
Termination Style J Lead
Current Rating 50mA
Orientation Straight
Voltage - Rated DC 12V
Additional Feature REEL PACKAGE
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TL3304
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Terminal Material BRASS
Actuator Material Rubber
Housing Material Polyphenylene
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Silver
Supply Chain
Factory Lead Time 11 Weeks
Alternative Model
