TL3301CF160RJ
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Tactile Switches
Description
Standard TL3301 Surface Mount Top Actuated Tactile Switch 8.00mm 0.05A 12V 0.05A @ 12VDC
PDF
/
Buying Options
Total Price: USD $2.24
Unit Price: USD $2.239807
≥1 USD $2.239807
≥200 USD $0.894085
≥700 USD $0.863888
≥1400 USD $0.849446
Inventory: 9777
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Body Height 3.6mm
Technical
Number of Switches 1
Actuator Height off PCB, Vertical 8.00mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 6.00mm
Contact (DC) Max Rating R Load .05A@50VDC
Actuator Orientation Top Actuated
Operating Force 160gf
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Contact Current(DC)-Max 0.05A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 6 mm
Body Length or Diameter 6mm
Termination Style J Lead
Current Rating 50mA
Packing Method TAPE AND REEL
Voltage - Rated DC 12V
HTS Code 8536.50.90.40
Terminal Finish Gold (Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series TL3301
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Actuator Material Polyamide (PA), Nylon
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Supply Chain
Factory Lead Time 10 Weeks
