TL3210AF160BQ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Buying Options
Total Price: USD $4.48
Unit Price: USD $4.4792
≥1 USD $4.4792
≥10 USD $4.08584
≥100 USD $3.716064
≥500 USD $3.21024
≥1000 USD $2.918362
≥3000 USD $2.704363
Inventory: 1137
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Actuator Length 1.1mm
Technical
Actuator Height off PCB, Vertical 3.12mm
Switch Travel 0.20mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 5.60mm x 3.40mm
Actuator Orientation Top Actuated
Illumination Type Illuminated, LED
Operating Force 160gf
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Max Voltage Rating (DC) 12V
Illumination Illuminated
Throw Configuration SPST
Electrical Life 100000 cycles
Illumination Type, Color LED, Blue
Illumination Voltage (Nominal) 3.3VDC
Contact Resistance 500mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Plunger for Cap
Termination Style Gull Wing
Orientation Straight
Color Blue
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
JESD-609 Code e4
Series TL3210
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
