TL3200AF160RRQ
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Buying Options
Total Price: USD $4.34
Unit Price: USD $4.3384
≥1 USD $4.3384
≥10 USD $4.1536
≥100 USD $3.7928
≥500 USD $3.286976
≥1000 USD $2.979962
≥3000 USD $2.763235
Inventory: 1554
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Actuator Height off PCB, Vertical 2.50mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.80mm x 4.50mm
Actuator Orientation Top Actuated
Illumination Color Red
Illumination Type Illuminated, LED
Operating Force 160gf
Mechanical Life 30,000 Cycles
Illumination Illuminated
Throw Configuration SPST
Illumination Type, Color LED, Red/Red
Illumination Voltage (Nominal) 2.3VDC
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Rectangular Button
Termination Style Gull Wing
Current Rating 50mA
Voltage - Rated DC 12V
Termination Gull Wing
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Series TL3200
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
Physical
Actuator Material Liquid Crystal Polymer (LCP)
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Supply Chain
Factory Lead Time 10 Weeks
