TL1105SPF160Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Plunger for Cap TL1105 Black Through Hole Tactile Switch 7.50mm 50mA 12V 0.05A @ 12VDC
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
≥10 USD $0.24992
≥100 USD $0.181914
≥500 USD $0.155188
≥1000 USD $0.142252
≥3000 USD $0.132766
Inventory: 1522
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Actuator Length 10mm
Body Height 3.6mm
Technical
Number of Switches 1
Actuator Height off PCB, Vertical 7.50mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 6.00mm
Contact (DC) Max Rating R Load .05A@12VDC
Actuator Orientation Top Actuated
Illumination Type Illuminated, Non-Illuminated
Operating Force 160gf
Contact Current Rating 50mA
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Max Voltage Rating (DC) 12V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 cycles
Contact Current(DC)-Max 0.05A
Contact Resistance 100mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Plunger for Cap
Body Breadth 6 mm
Body Length or Diameter 6mm
Termination Style PC Pin
Current Rating 50mA
Orientation Straight
Voltage - Rated DC 12V
Color Black
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series TL1105
Published 2001
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
Actuator Material Polyamide (PA), Nylon
Housing Material Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Contact Material Bronze, Silver
Supply Chain
Factory Lead Time 11 Weeks
