TL1105KF160Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Tactile Switches Thru hole 6mmx6mm SPST-NO 0.05A 50V
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
≥10 USD $0.30448
≥100 USD $0.286176
≥500 USD $0.2486
≥1000 USD $0.225491
≥3000 USD $0.209757
Inventory: 2674
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Actuator Height off PCB, Vertical 13.50mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 6.00mm
Actuator Orientation Top Actuated
Operating Force 160gf
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style PC Pin
Current Rating 50mA
Voltage - Rated DC 12V
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series TL1105
Published 2002
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
Actuator Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
