TL1105HF160Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Switch Tactile N.O. SPST Round Button PC Pins 0.05A 50VDC 1.57N Thru-Hole
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.2816
≥1 USD $0.2816
≥10 USD $0.27104
≥100 USD $0.232408
≥500 USD $0.167983
≥1000 USD $0.153982
≥3000 USD $0.143722
Inventory: 1375
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Bronze, Silver
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Housing Material Nylon
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 2006
Series TL1105
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Voltage - Rated DC 12V
Orientation Straight
Current Rating 50mA
Termination Style PC Pin
Body Length or Diameter 6mm
Body Breadth 6 mm
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 100mOhm
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 0.05A
Electrical Life 100000 cycles
Throw Configuration SPST
Illumination Non-Illuminated
Max Voltage Rating (DC) 50V
Mechanical Life 100,000 Cycles
Switch Type KEYPAD SWITCH
Contact Current Rating 50mA
Operating Force 160gf
Actuator Orientation Top Actuated
Contact (DC) Max Rating R Load .05A@12VDC
Outline 6.00mm x 6.00mm
Contact Rating @ Voltage 0.05A @ 12VDC
PCB Hole Count 4
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 12.50mm
Number of Switches 1
Dimensions
Body Height 3.6mm
Actuator Length 8.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
