TL1105CF100Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Tactile Switches Thru hole 6mmx6mm SPST-NO 0.05A 50V
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.1848
≥1 USD $0.1848
≥10 USD $0.17512
≥100 USD $0.12995
≥500 USD $0.108794
≥1000 USD $0.099722
≥3000 USD $0.093676
Inventory: 26741
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Silver
Mount Through Hole
Mounting Type Through Hole
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 2002
Series TL1105
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
HTS Code 8536.50.90.40
Voltage - Rated DC 12V
Current Rating 50mA
Termination Style PC Pin
Body Length or Diameter 6mm
Body Breadth 6 mm
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Current(DC)-Max 0.05A
Electrical Life 100000 Cycle(s)
Throw Configuration SPST
Illumination Non-Illuminated
Mechanical Life 100,000 Cycles
Switch Type KEYPAD SWITCH
Operating Force 100gf
Actuator Orientation Top Actuated
Contact (DC) Max Rating R Load .05A@12VDC
Outline 6.00mm x 6.00mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 8.00mm
Number of Switches 1
Dimensions
Body Height 3.6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
